Shanghai Haozhuang Instrument Co., Ltd. has developed a small spray dryer of the brand Hao Zhuang (LNB), which is energy-saving and environmentally friendly, leading the country. Professional manufacturing is more secure and affordable
Installation Notes
1. Installation of the drying chamber Hold the drying chamber with both hands and insert it into the fixing clamp of the drying chamber diagonally, and lock the lock nut of the drying chamber (subject to the rotation of the drying chamber in the clamp).
2. Installation of the cyclone separator Put the lock nut, seal ring and stainless steel gasket of the cyclone separator on the air outlet pipe of the cyclone separator, and then insert it into the air outlet pipe of the equipment together to adjust the air outlet of the drying chamber and the cyclone separator Position the air inlet so that the two ports are aligned straight, connect the two ports with a clamp, and finally lock the lock nut of the cyclone separator.
3. Connect the collection bottle to the cyclone separator with a clamp
4. Connect the collecting tube to the drying chamber with a clamp
5. Install the spray chamber on the device and connect a 4mm trachea (for needle) and a 6mm trachea (for spray)
6. Install the food-grade silicone tube to the peristaltic pump and insert it into the feed port of the spray chamber
Note: 1) All glass devices are fragile, please be careful when installing, removing and cleaning;
2) Make sure that all components are installed in place before powering on
Experiment preparation
1. Install all components according to the installation instructions.
2. Turn on the two air switches in the power distribution cabinet, close the power distribution cabinet door, press the green start button of the device, and the device is powered on.
3. Set the parameters and start the automatic control operation.
4. Feeding, observe the atomization and temperature change of the material, adjust the parameters, reset the fan, feed volume, inlet air temperature, or outlet air temperature, and feed after stabilizing.
