The rating of the salt spray corrosion test results of the paint coating is slightly different from the rating of the metal coating. It divided the evaluation results into 3 levels. According to the two of the three models with the same level, the evaluation principles are as follows:
Paint coating corrosion rating principle: grade damage
Level 1: slight discoloration; no bubble, rust, shedding, pitting, cracks, etc. in the paint film.
Level 2: Obvious discoloration; the area of ​​micro-bubbles on the surface of the paint film is less than 50%; the area of ​​local small bubbles is less than 4%; the area of ​​medium bubbles is less than 1%; the diameter of the rust spot is less than 0.5mm; the paint film does not fall off
Level 3: Severe discoloration; the area of ​​micro-bubbles on the surface of the paint film exceeds 50%; the area of ​​small bubbles is more than 5%; the area of ​​large bubble rust points is more than 2%; the paint film is peeled off
Note: â‘ Bubble area calculation: use a hundred percent grid, where 1% of the area is counted as 1% of the area as long as it is foamed, and so on, the bubble level is as follows: microbubbles: only visible to the naked eye; small Bubbles: Obviously visible to the naked eye, with a diameter below 0.5mm; Medium bubbles: 0.6-1mm in diameter; Large bubbles: 1.1mm in diameter.
â‘¡The surrounding edges of the board (including the edge seal) and the 5mm around the hole are not evaluated, and the damage caused by external factors is not calculated.
③The area of ​​raw white rust is less than 10%, and the red rust is totally unqualified.
â‘£The phenomenon of paint film damage is in accordance with any one of the grades specified in the above table.
