During the summer operation of the air conditioner, when the air conditioner performs the cooling operation, when the indoor air flows through the evaporator of the air conditioner, the water vapor condenses to form condensed water, and the condensed water flows out along the drain pipe, but after a long time of use Can not be naturally discharged, then the decoration of the home decoration network Xiaobian to tell everyone the reasons and treatment of air conditioning condensate .
What is the cause of air conditioning condensate?
The entire air conditioning system produces two main areas of condensate: one is the air cooler of the air handling unit, and the other is the end of the air conditioner (such as a wet fan coil). The mechanism of condensate production is the same. The air treatment unit and the air conditioner end respectively generate condensed water for drying fresh air and eliminating indoor wet load.
1. The reason why the gas treatment unit produces condensed water: when the outdoor air (or mixed with fresh air and return air) exchanges heat with the air cooler of the air treatment unit to cool the dehumidified air, the wall temperature of the surface cooler is lower than the outdoor air. (or mixed wind) dew point temperature, the water vapor contained in the outdoor air (or mixed air) is precipitated on the surface of the surface cooler and dews. When the dewdrop increases to a certain extent, it will slide down to the condensate pan below the air cooler. Condensed water is formed. Condensate treatment: Connect the condensate pipe to the condensate pan to discharge the condensate to the appropriate place.
2. The reason for the condensation at the end is that the air conditioner ends and the indoor air exchange heat to cool the dehumidified air. Since the wall temperature of the air conditioner terminal is lower than the indoor air dew point temperature, the water vapor contained in the indoor air will be precipitated on the end wall of the air conditioner. Dew, when the dewdrop is increased to a certain extent, it will slide down to the condensate pan below the end of the air conditioner, thus forming condensed water. Condensate treatment: Treatment of condensate at the end of the air conditioner A special condensate system in the air-conditioning water system discharges the condensate from the end of the air conditioner.
Air conditioning outlet condensate solution
1. The wooden air outlet can be used. The general outlet condensation is excessive humidity in the room, which can increase the air temperature.
2, air-conditioned doors and windows are best closed, do not let the outdoor hot and humid air to adjust the room temperature. Since the air conditioner itself has dehumidification capability, as the air conditioner operates, the indoor air humidity will gradually decrease and the condensation will gradually decrease until there is no condensation.
3, indoor temperature set point, at the beginning, can be set to 26 degrees -28 degrees, after a period of time to adjust to the required temperature.
4 Condensation is because the air temperature is lower than the dew point temperature, the air and the outlet make different nozzles, or increase the air volume.
5. If it is a louvered tuyere, you can adjust the angle of the blade to make the exit turbulent.
6. If the wood is more expensive, you can install a thin PE insulation board at the exit of the existing central air conditioner.
The above are the knowledge of air conditioning condensate provided by everyone in the decoration home decoration network Xiaobian, I hope to help everyone. If you want to know more about decoration, please continue to pay attention to the decoration home network.
